47µH  0.7A SMD Power Inductor  CD54-470
xxx
Item # 17010
SMD Unshielded Power Inductor
Description: SMD Unshielded Power Inductor

CD54 Series ,Various high power inductors are superior to be high saturation for surface mounting.
Mainly used by power supply for VRT,OA equipment Digital camera,LCD television set notebook PC,partable communication equipments,DC/DC converters, etc.

Inductance : 47 µH +/- 20%
DC Resistance (max.): 0.370  Ω
Saturation current  Isat :  0.72 A
Test Frequency: 100KHz / 1V
Operating Temperature: -40°C to +100°C
Inductance drop: 10% at Isat.

Description:
• Ferrite drum core construction.
• Magnetically unshielded.
• L×W×H: 6.1×5.5×4.85mm Max.
• Product weight 0.4g(Ref.)
• Moisture Sensitivity Level: 1
• Operating temperature range: -40℃ to +125℃;
• Solder reflow temperature: 260 ℃ peak.
• RoHS compliance.

Applications:
 - DC-DC converter of portable equipment.
 - Camcoder, LCD television set, Digital camera, P.D.A., Notebook.
Marking Code: 470
Documents & Files:
cn_D_1_107.pdf
Datasheet
CD54-LF.pdf
LFCurve


Quantity:
Price:
$0.49  USD
per Unit
