PIC12C509A  Microcontroller
Item # 10265
Microchip PIC12C509A
8-Pin, 8-Bit CMOS Microcontroller
Package type: DIP 8-pin
Description: This powerful (1µsecond instruction execution) yet easy-to-program (only 33 single word instructions) CMOS OTP-based 8-bit microcontroller packs Microchip’s powerful PIC® architecture into an 8-pin package.
Easily adapted for automotive, industrial, appliances and consumer entry-level product applications.

● Program Memory: 1.5 Kbytes.
● Program Memory Type: OTP
● Data Memory: 41 Bytes
● Data EEPROM: None
● CPU Speed: 1 MIPS
● Timers: 1 x 8-bit
● ADC: None
● Comparators: None
● Operating Voltage Range: 2.5V to 5.5V
● Internal Oscillator: Yes
● Max Operating Frequency: 4 MHz
● Temperature Range: 0C to +70C
● I/O Pin Count: 6 with 25mA source/sink per I/O
● Pin Count: 8
● XLP: No

PIC12F509A Microcontroller
Documents & Files:
PIC12C5XX / CE5XX Datasheet

RoHS Compliant
China EFUP

$1.00  USD
per Unit
