FSMD010-1206-R  SMD Resettable Fuse - 1206 POLY PPTC PTC  60V  0.1A
Item # 15063
FSMD010-1206
FSMD010-1206-R

FSMD1206 Series

RoHS Compliant & Halogen Free
Package type: SMD 1206
Description: SMD - Surface Mount Polymer PTC Resettable Fuse

Features:
 ● Faster time to trip than standard SMD devices.
 ● Lower resistance than standard SMD devices.
 ● Solid state.
 ● Temperature Range : -40℃ to 85℃
 ● RoHS compliant and Halogen Free.
 ● SMD Package Type: 1206
      - Dimensions (inches): 0.12 x 0.06
      - Dimensions (mm): 3.0 x 1.5

Applications:
 • All high-density boards.

Electrical Characteristics:
 ●
Hold current ( I hold ) : 0.1A
maximum current device will pass without tripping in 23°C still air.
 ●
Trip current  ( I trip ) : 0.25A
minimum current at which the device will trip in 23°C still air.
 ●   Maximum fault current ( I max ) : 100A
Maximum fault current device can withstand without damage at rated voltage (Vmax)
 ●
Maximum voltage ( V max ): 60V dc
Maximum voltage device can withstand without damage at rated current (I max)
 ●
Resistance ( R min ) :  1.6 Ω
Minimum resistance of device in initial (un-soldered) state.
Marking Code: FA
Documents & Files:
Manufacturer website: [Click here]


Quantity:
Price:
$0.15  USD
per Unit
