100µH SMD Power Inductor  CD54-101
xxx
Item # 17018
SMD Unshielded Power Inductor
Description: SMD Unshielded Power Inductor

CD54 Series ,Various high power inductors are superior to be high saturation for surface mounting.
Mainly used by power supply for VRT,OA equipment Digital camera,LCD television set notebook PC,partable communication equipments,DC/DC converters, etc.

Inductance : 100 µH +/- 20%
DC Resistance (max.): 0.700  Ω
Isat :  0.52A
Test Frequency: 100KHz / 1V
Operating Temperature: -40°C to +100°C
Inductance drop: 10% at Isat.

Description:
• Ferrite drum core construction.
• Magnetically unshielded.
• L×W×H: 6.1×5.5×4.85mm Max.
• Product weight 0.4g(Ref.)
• Moisture Sensitivity Level: 1
• Operating temperature range: -40℃ to +125℃;
• Solder reflow temperature: 260 ℃ peak.
• RoHS compliance.

Applications:
 - DC-DC converter of portable equipment.
 - Camcoder, LCD television set, Digital camera, P.D.A., Notebook.
Marking Code: 101
Documents & Files:
cn_D_1_107.pdf
Datasheet
CD54-LF.pdf
LFCurve


Quantity:
Price:
$0.28  USD
per Unit
