SPX3819M5  5V  500mA Low-Noise LDO Voltage Regulator
Item # 20305
SMD
5.0V  500mA Low Noise LDO Voltage Regulator

SPX3819
SPX3819M5
SPX3819M5-L-5-0
SPX3819M5-L-5-0/TR

Fixed Output Voltage: 5.0V

Halogen free
Package type: SOT-23-5
Description: The SPX3819 is a positive voltage regulator with a low dropout voltage and low noise output. In addition, this device offers a very low ground current of 800μA at 100mA output.

The SPX3819 is an excellent choice for use in battery powered applications such as cordless telephones, radio control systems and portable computers.
It is available in several fixed output voltage options or with an adjustable output voltage.
The SPX3819 has an initial tolerance of less than 1% max and a logic compatible on/off switched input.
When disabled, power consumption drops to nearly zero.
Other key features include reverse battery protection, current limit and thermal shutdown.
The SPX3819 includes a reference bypass pin for optimal low noise output performance.
With its very low output temperature coefficient, this device also makes a superior low power voltage reference.

Features:
 ●  Fixed output: 5V
 ●  Low noise: 40µV possible
 ●  High accuracy: 1%
 ●  Reverse battery protection
 ●  Low dropout: 340mV at full load
 ●  Low quiescent current: 90µA
 ●  Zero off-mode current
 ●  Temperature Range: -40°C ≤ TJ ≤ +125°C
 ●  5-pin SOT-23 package



Marking Code: M3xx
Documents & Files:
SPX3819_DS_R202_052014-1.pdf
Datasheet
spx3819.pdf
Datasheet
spx3819faq.pdf
SPX3819 FAQ
anp-02.pdf
Application Note: Thermal Considerations
spx3819m5-l-5-0 CAD File.bxl
Symbols & Footprints
Manufacturer website: [Click here]
