Description: Kanthal is the trademark for a family of iron-chromium-aluminium (FeCrAl) alloys used in a wide range of resistance and high-temperature applications.
Kanthal A1 Wire is well known around the world for its heat resistant properties. It has a high heat resistance up to 1400°C (2600°F), with a melting point of 1600°C
Kanthal A-1 is a ferritic iron-chromium-aluminium alloy (FeCrAl alloy) rated for use at temperatures up to 1400°C (2600°F). The alloy has high resistivity and great oxidation resistance. It is typically used in furnace applications, such as electrical heating elements in high-temperature furnaces for heat treatment, glass, steel, ceramics, and electronics industries.
● Alloy: Kanthal A-1 (22% Cr, 5.8% Al, Fe balance)
● Gauge: 28 AWG
● Average wire diameter: 0.32 mm
● wire length: 50cm
● Shape: Round
● Heat treatment: Annealed (soft)
● Resistance (Ohms/ft. @ room temp): 5.27
● Melting temperature: 1500°C (2730°F)
● Maximum operating temperature: 1400°C (2550°F)
● Density: 0.256 lbs. per cubic inch
● Specific heat capacity at 20°C (68°F): 0.46 kJ/kg K (0.11 Btu/lb°F)
