Description: Transient-Voltage-Suppression (TVS) diode is an electronic component used to protect sensitive electronics from voltage spikes induced on connected wires.
Typical Applications:
Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, and telecommunication.
Features:
• 600 W peak pulse power capability
• Peak forward surge current 8.3 ms single half sine-wave: 100 A
• Stand-Off Voltage Vwm: 6.5 V
• Min. Breakdown Voltage vbr: 7.22 V
• Max. Breakdown Voltage vbr: 7.98 V
• Polarity: Uni-directional
• Very fast response time
• Low profile package
• Operating junction and storage temperature range: -55 to +150 °C
• Device Marking Code: KK
Polarity: For uni-directional types the band denotes cathode end, no marking on bi-directional types
