FSMD050-2920-R SMD Resettable Fuse - 2920 POLY PPTC PTC  60V  0.5A
Item # 15065
FSMD050-2920
FSMD050-2920-R

FSMD2920 Series

RoHS Compliant & Halogen Free
Package type: SMD 2920
Description: SMD - Surface Mount Polymer PTC Resettable Fuse

Features:
 ● Faster time to trip than standard SMD devices.
 ● Solid state.
 ● Temperature Range : -40℃ to 85℃
 ● RoHS compliant and Halogen Free.
 ● SMD Package Type: 2920
      - Dimensions (inches): 0.29 x 0.20
      - Dimensions (mm): 7.4 x 5.1

Applications:
 • All high-density boards.

Electrical Characteristics:
 ●
Hold current ( I hold ) : 0.5A
maximum current device will pass without tripping in 23°C still air.
 ●
Trip current  ( I trip ) : 1A
minimum current at which the device will trip in 23°C still air.
 ●   Maximum fault current ( I max ) : 100A
Maximum fault current device can withstand without damage at rated voltage (Vmax)
 ●
Maximum voltage ( V max ): 60V dc
Maximum voltage device can withstand without damage at rated current (I max)
 ●
Resistance ( R min ) :  0.3 Ω
Minimum resistance of device in initial (un-soldered) state.
Marking Code: F050L
Documents & Files:
Manufacturer website: [Click here]

RoHS Compliant

Quantity:
Price:
7.50  EGP
per Unit
