TVS Diode  P4SMA6.8CA  5.8V 400W  Bi-directional
xxx
Item # 14064
P4SMA6.8CA
Surface Mount Transient Voltage Suppressors.
Bi-directional  TVS Diode
Package type: DO-214AC (SMA)
Description: Transient-Voltage-Suppression (TVS) diode is an electronic component used to protect sensitive electronics from voltage spikes induced on connected wires.

Typical Applications:
Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, and telecommunication.

Features:
• 400 W peak pulse power capability
• Stand-Off Voltage Vwm: 5.8 V
• Min. Breakdown Voltage vbr: 6.45 V
• Max. Breakdown Voltage vbr: 7.14 V
• Polarity: Bi-directional
• Very fast response time
• Low profile package
• Operating junction and storage temperature range: -65 to +150 °C
• Device Marking Code: 6V8C

Some Help About How to Select the Right TVS Diode For Your Application:
 • TVS Diode Selection - Semtech (pdf file)
 • How To Select Transient Voltage Suppressors (pdf file)
 • TVS Diode Selection Guide Tutorial (web page)

Polarity: For uni-directional types the band denotes cathode end, no marking on bi-directional types
Marking Code: 6V8C
Documents & Files:
p4sma.pdf
Datasheet
protrtv.pdf
Protecting for Repetitive Transient Voltages
What_are_TVS_Diodes.pdf
What are TVS Diodes
Manufacturer website: [Click here]


Quantity:
Price:
12.00  EGP
per Unit
