Description: The 467 Series Fast-Acting Surface Mount Fuse (SMF) is an ultra small (0603 size) thin-film device designed for secondary protection of circuits used in space constrained applications such as hand-held portable electronic devices. This series is 100% lead-free and meets the requirements of the RoHS directive.
Electrical Characteristics:
● Ampere Rating: 1.5A
● Max Voltage Rating: 32V AC/DC
● Body: Advanced High Temperature Substrate
● Nominal Melting I2T : 0.0766 A2sec
● Interrupting Rating: 35A @ 32 VAC/VDC
● Operating Temp Range: - 55°C to 90°C
● Nominal Power Dissipation: 0.1074 W
● Nominal Voltage Drop: 71.6 mV
● Nominal Cold Resistance: 0.0385 Ohms
● Opening: Very Fast-Acting (FF)
● Marking Code: K
● Package Size: 0603 (1608)
● Dimensions: 1.6mm x 0.8mm
Features:
| ● | Complies with electronic industry environmental standards for lead reduction |
| ● | Product is compatible with lead-free solders and higher temperature profiles |
| ● | High performance materials provide improved performance in elevated ambient temperature applications |
| ● | Product is marked on top surface with code to allow amperage-rating identification without testing |
| ● | Low profile for height sensitive applications |
| ● | Flat top surface for pick-and-place operations |
| ● | Element-covering material is resistant to industry standard cleaning operations |
| ● | Mounting pad and electrical performance are identical to Littelfuse 431 and 434 Series products |
