Red Vinyl-Insulated Ring Terminal 19A for AWG 22-16
Item # 17708
Model  RVS1.25-5

Quantity: 1 piece
Description: Pre-insulated Ring Terminal
The pre-insulated terminal is easy to connect with electrical wire to strengthen its reliability and safety.
Used widely in the machiney, electric power, railway, shipbuilding, aviation, home appliance, computer or other automatic equipments.

Features:
• Maximum electrical conductivity after crimping
• Funnel edged barrel for fast, easy insertion of wire
• Maximum holding power
• Tin plating prevents corrosion
• Wire range clearly stamped on neck of terminal
• Terminals are color coded by wire range for easy wire identification.

22-18 GA 16-14 GA 12-10 GA 8 GA 6 GA 4 GA

Specifications:
● Model: RVS1.25-5
● Terminal material: Copper
● Terminal surface treatment: Tin plated
● Insulation material: PVC = Polyvinylchloride (Vinyl)
● Insulation Color: Red
● Wire size range: 0.5 - 1.5mm² (A.W.G 22 - 16)
● Gauge: 22-16
● Max. Current: 19A



● Stud Diameter: #10 (USA Screw #10 / 4.83mm)
● Stud hole Diameter (d2) : 5.1mm
● Ring Outer Diameter (W): 8.0mm / 0.315"
● Tube Inner Diameter: 4.3mm / 0.169"
● Total Length (L): 21.5mm / 0.85''

Marking: Wire size & bolt size (22-16 & 1.25-5)
Marking Code: 22-16 & 1.25-5
