10K ohm SMD Resistor 1/4W  5%  (strip of 10)
Item # 2015
Strip of 10 pieces SMD Resistor.
10K ohm 1/4W SMD 1206 Resistor  5%

Items per lot: 10
Package type: SMD 1206
Description:

General purpose thick film resistor
Thick Film Chip Resistor
CR Series1206 ±5% 100 1/4W Series10kΩ 5K/REEL
Part: CR-06JL7---10K

Specifications:
● Resistor Value: 10K ohm
● Resistor Type: Fixed Value SMD Resistor
● Case Size Code:
1206 (Imperial )
3216 (Metric)
● Power rating : 1/4 Watt
● Max Operating Temperature: 155 °C
● Min Operating Temperature: -55 °C
● Resistance: 10 kΩ
● Temperature Coefficient: ±100 ppm/°C
● Max. Working Voltage:  200V
● Max. Overload Voltage: 400V
● Tolerance: 5 %
● Termination: Solder
● Mount: Surface Mount

Features:
• 10K ohm SMD Resistor
• Case Size (3.2 mm x 1.6 mm)
• Low tolerance (5 %)

Applications
● Telecommunication Equipments
● Radio and Tape Recorders, TV Tuners
● Digital Cameras, Watches, Pocket Calculators
● Computers, Instruments
● Medical and Military Equipment

Marking Code: 103
Documents & Files:
Manufacturer website: [Click here]

RoHS Compliant

Quantity:
Price:
$0.19  USD
per Lot
(10 items per lot)
Wholesale Pricing:
Qty.Price per Lot
(10 items per lot)
1 - 9$0.19  USD
10 - ∞$0.18  USD
