SS34 Low Drop Power Schottky Rectifier 40V 3A (SMD 1N5822 )
Item # 70473
1N5822
Surface Mount Schottky Barrier Rectifier

For the thru hole package of this diode [Click here]
Package type: DO-214AC (SMA)
Description:
The SS32-S310 series includes a high-efficiency, low power loss, general-propose Schottky rectifiers.
The clipbonded leg structure provides high thermal performance and low electrical resistance. These rectifiers are suited for free wheeling, secondary rectification, and reverse polarity protection applications.


Features:
• Metal to Silicon Rectifiers, Majority Carrier Conduction
• Low-Forward Voltage Drop
• Easy Pick and Place
• High-Surge Current Capability

Electrical Specifications:
• Repetitive peak reverse voltage (VRRM) : max. 40 V
• Continuous forward current (IF): 3 A
• Forward voltage (VF): 0.5 V
• Operating Junction Temperature(Tj): -55 to +150 °C
• Package Type: SMC

For use in low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
Marking Code: SS34
Documents & Files:
SS39-D.PDF
Datasheet
Similar products:



Quantity:
Price:
2.50  EGP
per Unit
