SS14 Low Voltage Drop Schottky Barrier Diode 40V 1A (SMD 1N5819)
Item # 70478
1N5819
1N5819W
SMD Schottky Rectifier

For the thru hole package of this diode [Click here]

Package type: DO-214AC
Description: The SS series is a high efficiency, low power loss general propose Schottky rectifier. The clip bonded leg structure provides high thermal performance and low electrical resistance. this rectifier is exclusively suits for free wheeling, secondary rectification and reverse polarity protection applications.

Features:
● Glass-Passivated Junctions
● High-Current Capability, Low VF

Characteristics:
• Maximum Peak Repetitive Reverse Voltage VRRM : 40V
• Maximum Average Forward Current I: 1.0A
• Forward Voltage VF: 0.5V
• Operating Junction Temperature Range(TJ): -65 to + 125 °C
• Thermal Resistance (Junction to Ambient): 88°C/W

Applications:
● Low Voltage
● High-Frequency Inverters
● Free Wheeling
● Polarity Protection

Marking Code: SS14
Documents & Files:
SS12-S100.pdf
Datasheet


Quantity:
Price:
$0.11  USD
per Unit
