36 Watt UV Curing Lamp
xxx
Item # 8109
Description:
High efficiency, 36W Professional UV curing lamp is operated with 4 x 9W UV light bulbs (included)
Cure time average for UV light is 2-4 minutes

Can be used for a maximum PCB size: 14 x 14 cm

Properties:
•  Weight: 1.7 kg
•  Dimensions: 100 X 220 X 240 mm
•  Power: 36 W
•  Voltage 220 V - 240 V, 50 Hz
•  Timer Duration: 120 seconds
•  Works with 4 x 9 watt UV bulbs, regularly replace the lamps to always have optimal efficiency.
•
Strongest wavelength: 370 µm (This wavelength is visible in the light and harmless to the eyes but do not be careful not to look too long at the bulb.)


DESCRIPTION Fig. 1
1. Lamp body in plastic
2. 4 bulbs UV, 9W each
3. Switch on/off I/0, and “timer” II
4. Timer 120 seconds
5. Fuse
6. Mirror effect internal for a perfect drying
7. Slide base plate for plugging/replacing the bulbs

USE
O = switch off
II = timer
I = switch on
Red button: switch 120 second timer on.

INSTRUCTION:
Before use please read instructions carefully.
•
While inserting or replacing the UV bulb the lamp has to be switched off and unplugged.
•  Do not get into contact with water.
•  If not in use, switch it off and disconnect from the power.
•  Do not look straight into the illuminated bulbs.
•  Note that over exposure to ultra violet radiation/UV lamps can cause skin or eye damage.
•  Whenever you recognize a changing of the skin, seek medical advice.
•  The lamp is for indoor use only therefore never use it outdoor.
•  Malfunction has to be solved by an expert.

CLEANING
• Clean only with a smooth dry cloth.
• Do not use any dissolver or detergent.
• Store in a dry and safe place. Keep out of reach of children.

TECHNICAL DATA
Power 220V–240V~50/60Hz
Max. capacity :36W
UV bulbs: 9W, 365 nm


Never leave the appliance unattended as long as the power plug is connected with the power outlet.
Do not use if the UV nail lamp is damaged; contact directly the provider or assistance centre.
