Blue Vinyl-Insulated Pin Terminal 27A for AWG 16-14
Item # 17705
Insulated Pin Terminal

Model  PTV2-10

Quantity: 1 piece
Description: Pre-insulated Pin Terminal
The pre-insulated terminal is easy to connect with electrical wire to strengthen its reliability and safety.
Used widely in the machiney, electric power, railway, shipbuilding, aviation, home appliance, computer or other automatic equipments.

Features:
• Maximum electrical conductivity after crimping
• Funnel edged barrel for fast, easy insertion of wire
• Maximum holding power
• Tin plating prevents corrosion
• Wire range clearly stamped on neck of terminal
• Terminals are color coded by wire range for easy wire identification.

22-18 GA 16-14 GA 12-10 GA 8 GA 6 GA 4 GA

Specifications:
● Model: PTV2-10
● Shape: Male
● Terminal material: Copper
● Terminal surface treatment: Tin plated
● Insulation material: PVC = Polyvinylchloride (Vinyl)
● Insulation Color: Blue
● Wire size range: 1.5 - 2.5mm² (A.W.G 16 - 14)
● Gauge: 16-14
● Max. Current: 27A

● Pin Diameter (d2) : 1.9mm
● Tube Inner Diameter: 4.8mm / 0.189"
● Total Length (L): 19.7mm / 0.77''



Quantity:
Price:
0.50  EGP
per Unit
Wholesale Pricing:
Qty.Price per Unit
1 - 40.50  EGP
5 - ∞0.40  EGP
