LL4148 High-Speed Switching SMD Diode  200mA 100V  (strip of 10)
xxx
Item # 2648
Strip of 10 pieces SMD Doide.
LL4148  is high-speed switching SMD diode
Small Signal Fast Switching Diode
Electrically equivalent diodes: 1N4148 , 1N4148 , 1N914


Items per lot: 10
Package type: SOD-80
Description: The LL4148  is high-speed switching diode.
Small Signal Fast Switching Diodes

Features:
• SMD (SOD-80) package
• High switching speed: max. 4 ns
• General applications

Characteristics:
• Repetitive peak reverse voltage (VRRM) : max. 100 V
• Continuous reverse voltage (VR): max. 75 V
• Continuous forward current (IF): 200 mA
• Repetitive peak forward current (IFRM): max. 500 mA.
• Forward voltage (VF): 1 V
• Reverse Recovery Time:  4.0 ns
• Operating Junction temperature Range (Tj): -55 to +175 °C

Applicatons:
• High-speed switching.
• Extreme fast switches
Documents & Files:
LL4148.pdf
Datasheet


Quantity:
Price:
5.50  EGP
per Lot
(10 items per lot)
