1N4148  High-speed switching diode 200mA 100V
Item # 2314
1N4148 is high-speed switching diode
Electrically equivalent diodes: 1N4148 - 1N914
Package type: DO-35
Description: The 1N4148 is high-speed switching diode fabricated in planar technology, and encapsulated in hermetically sealed leaded glass SOD27 (DO-35) package.

Features:
• Hermetically sealed leaded glass SOD27 (DO-35) package
• High switching speed: max. 4 ns
• General application

• Repetitive peak reverse voltage (VRRM) : max. 100 V
• Continuous reverse voltage (VR): max. 100 V
• Continuous forward current (IF): 200 mA
• Repetitive peak forward current (IFRM): max. 450 mA.
• Forward voltage (VF): 1 V
• Junction temperature (Tj): 200 °C

Applicatons:
• High-speed switching.
• Extreme fast switches
Documents & Files:
1N4148_1N4448.pdf
Datasheet


Quantity:
Price:
$0.05  USD
per Unit
Wholesale Pricing:
Qty.Price per Unit
1 - 24$0.05  USD
25 - ∞$0.05  USD
