AO3401  P-Channel MOSFET transistor (SMD)
Item # 330
AO3401  P-Channel MOSFET transistor.
VDS : -30 V
I:  -4.0 A
Package type: SOT-23
Description: The AO3401 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a load switch or in PWM applications.

Maximum drain-source voltage  VDS : -30 V
Maximum gate-source voltage  VGS : ±12 V
Maximum continuous drain current  I:  -4.0 A
Maximum power dissipation P: 1.4 W
Junction and Storage Temperature Range:  -55 to 150 °C

Drain-source on-resistance:
    at (VGS =-10V):  < 50 mΩ
    at (VGS=-4.5V) : < 60 mΩ
    at (VGS=-2.5V):  < 85 mΩ

Marking Code: A1xx
Documents & Files:
AO3401.pdf
Datasheet
AO3401_Marking.pdf
Marking
SOT-23-3L.pdf
Package
AO3401_ReliabilityReport.pdf
Reliability Report
Manufacturer website: [Click here]
Similar products:


RoHS Compliant

Quantity:
Price:
2.50  EGP
per Unit
