Description: High quality photosensitive dry film for PCB
Acting Type: Negative Acting.
Film Size: 30 x 20 cm
● High sensitive photo resist film
● Short exposing time:
1~2 minutes when using ultraviolet lamp
6~10 minutes when using Fluorescent lamp
PCB photosensitive dry film for circuit production 30cm x 20Cm
Features:
-Photographic film, also known as dry film, is used to make PCB board, stick it on top of the PCB, it will become a sensitive circuit board.
-Suitable for plating, hole coveringand the etching process.
-Excellent ability to cover holes
-High Resolution
-Excellent adhesion to almost all surfaces
-Image clarity after exposure
-Front-panel is very clean after developed
Etching:
The dry film is resistant to most of the acid etching solution, the PH value can be resistant to most alkaline etching solution between PH8.0 ~8.5.
Cover hole:
1.5 mil dry film can fully cover a 0.25 inches thickness hole.
Plating:
The dry film is available in most common use of the plating bath, no wrinkles, no color.
How to use it: Dry Film Resist Instructions
Open its bag in a dark place
