30 x 100 cm Photosensitive film for PCB (Negative Acting)
xxx
Item # 30467
High quality negative acting photosensitive film for PCB
(Board not included).

 High quality
Description: High quality photosensitive dry film for PCB

Acting Type: Negative Acting.
Film Size: 30 x 100 cm

● High sensitive photo resist film
● Short exposing time:
     1~2 minutes when using ultraviolet lamp
     6~10 minutes when using Fluorescent lamp

PCB photosensitive dry film for circuit production 30cm x 20Cm

Features:
-Photographic film, also known as dry film, is used to make PCB board, stick it on top of the PCB, it will become a sensitive circuit board.
-Suitable for plating, hole coveringand the etching process.
-Excellent ability to cover holes
-High Resolution
-Excellent adhesion to almost all surfaces
-Image clarity after exposure
-Front-panel is very clean after developed

Etching:
The dry film is resistant to most of the acid etching solution, the PH value can be resistant to most alkaline etching solution between PH8.0 ~8.5.

Cover hole:
1.5 mil dry film can fully cover a 0.25 inches thickness hole.

Plating:
The dry film is available in most common use of the plating bath, no wrinkles, no color.


How to use it:  Dry Film Resist Instructions

Open its bag in a dark place


Quantity:
Price:
80.00  EGP
per Unit
