MCP2200  USB 2.0 to UART Protocol Converter
Item # 10261
Microchip MCP2200 SMD
USB 2.0 to UART Protocol Converter with GPIO
Package type: SOIC 20-pin
Description:
 * Uses standard Windows® drivers for Virtual Com: Windows XP (SP2 or later), Vista, 7
 * Eight general purpose I/O pins.
 * 256 bytes of user EEPROM.
 * USB activity LED outputs (TxLED and RxLED).
 * Oscillator input: 12 MHz.

Characteristics:
● USB Speed: Full Speed.
● USB Compliant: USB 2.0
● MCU Interface: UART
● Tx/Rx Buffer Size: Tx 128 - Rx 128 Bytes
● No. of GPIO: 8 Pin
● MCU Interface: UART
● Operating Voltage Range: 3.0 to 5.5V
Documents & Files:
22228B.pdf
Data Sheet
51901A.pdf
MCP2200 USB to RS-232 Demo Board
93066A.pdf
MCP2200 HID Interface Command Description
MCP2200 Configuration Utility v1.3.1.zip
Configuration Utility
MCP2200 Production Utility.zip
Production Utility
MCP2200 Windows Driver 2013-02-21.zip
Windows Driver
MCP2200_DLL_2013-01-28.zip
DLL and Example Code (VB.NET & C# & C++)
Similar products:


RoHS Compliant
China EFUP

Currently
Out of stock
Price:
$4.28  USD
per Unit
